CS-4510ES

Rear handle professional chain saw that exceeds expectations. Featuring a powerful 45cm³ engine and weighing only 5kg, this robust saw will see you through any job.

€460.00

Where to buy
CS-4510ES
Scroll
scroll

The CS-4510ES is a great all-round chain saw with enough power to take on more heavy duty tasks. Equipped with a 45.0cm³ professional grade engine and packed full of features to make your job easier. ES Start, ECHO's patented easy start system ensures your engine starts with ease, every single time. A newly designed air filter system is both easy to access and extremely effective at keeping your machine free from dust and debris. Weighing in at just 5.0kg, the saw has an excellent power-to-weight ratio, making it ideal for a range of jobs.

Professional engine

Professional engine

45.0cm³ professional-grade, 2-stroke engine provides category-leading cutting performance for better work efficiency.

Ergonomic

Ergonomic

Small, lightweight design alongside a powerful engine for a superb power to weight ratio.

Comfortable

Comfortable

Tool-less air filter cover allowing easy air filter access, even when wearing gloves; a side access chain tensioner enabling easy chain adjustment; an anti-icing system preventing the carburettor from freezing in colder months.

Best Features.

Power to weight ratio

Super light-weight design with exceptional power.

Ergonomics

Designed to maximise efficiency and comfort.

Easy start engine

ECHO’s patented system for effortless starting.

Product Details.

Engine displacement (cm³) 45.0
Output (kw) 2.3
Output (ps) 3.1
Dry Weight (kg) 5.0
Fuel tank capacity (l) 0.48
Chain Oil Tank Capacity 0.330
Fuel Consumption At Maximum Engine Power (L/h) 1.19
Priming Pump Yes
Ignition System CDI
Start Assist System ES-start
Chain Brake Inertia
Choke w/ Automatic Fast Idle Release Yes
Chain Tensioner Side
Saw Chain Pitch (inch) 0.325
Guide Bar Gauge (inch) 0.058, 0.050
Applicable Bar Length (cm/inch) 1 33, 38, 45, 50 / 13, 15, 18, 20
Vibration Front handle/Rear handle (m/s²) 2.6 / 2.8
Sound power level (dB(A)) 111.6
Sound pressure level (dB(A)) 102.5
CO² (g/kW・h) 2 803
1
Not all lengths available in every country. Available bar lengths may incur differing RRPs. Please check with your local dealer.
2
This CO² measurement results from testing a (parent) engine representative of the engine type (engine family) over a fixed test cycle under laboratory conditions and does not imply or express any guarantee of the performance of a particular engine.

Other Features.

ES-start
Fast Idle
G-FORCE Engine Air Pre-Cleaner
Model certified or CE
Side access chain tensioner
Spike
